![Logo Webhooks](https://services.glpi-network.com/documentation/1533/download_file/main/docs/logo.png) # Plugin Collaborativetools for GLPI ## Purpose This plugin aims to provide connectors for web collaborative tools. It currently push notifications to HTTP `incoming webhooks` for the following services: ### Mattermost ![Mattermost](https://services.glpi-network.com/documentation/1533/download_file/main/docs/logos/mattermost.png) > #### Setup > As a logged team administrator, go to the main menu and click on `Integrations` sub link, select `incoming webhooks`, add a new one, define a title and select a channel. > After save, you will get the url of the webhook. ### Microsoft Teams ![Microsoft Teams](https://services.glpi-network.com/documentation/1533/download_file/main/docs/logos/microsoft_teams.png) > #### Setup > You need to add a `connector` on your channel (by right clicking on it), select `Incoming Webhooks`, set a name and add optionnaly an image. > After save, you will get the url of the webhook. ### Rocket.Chat ![Rocket.Chat](https://services.glpi-network.com/documentation/1533/download_file/main/docs/logos/rocket_chat.png) > #### Setup > As a logged team administrator, go to the administration menu and click on `Integrations` menu item. Click on the `New integration` button, select `incoming webhooks`, and define webhook parameters. > After save, you will get the url of the webhook. ### Slack ![Slack](https://services.glpi-network.com/documentation/1533/download_file/main/docs/logos/slack.png) > #### Setup > You need to add an `application` to your team (the link is present in the bottom of the left side bar) and select `incoming-webhook`. > Add a new configuration, select the channel where you want notifications and you will get the webhook url. > You can optionally setup a name and a logo for your hook. ### Telegram ![Telegram](https://services.glpi-network.com/documentation/1533/download_file/main/docs/logos/telegram.png) > #### Setup > First you need to create a `Telegram bot` by talking to `@BotFather` inside Telegram. You will get an API token corresponding to this bot. The webhook URL will be `https://api.telegram.org/bot<token>`. > Then you need to add this bot, as an administrator, on the channel where you want notifications. > Telegram API requires an additional parameter, called `chat_id`, that corresponds to your channel id. To get it, forward any message from your channel to the `@getidsbot` bot and get the id value of the `forward_from_chat` message property. ## GLPI Setup After installing and enabling Plugin in `Setup > Plugins`, you will find a new entry in `Setup > Dropdowns` labelled `Collaborative tools > Webhooks`. You can define here the list of your services' webhooks. When adding one, paste the url you got in the specific setup of the service. After this, go to `Setup > Notifications`, then: - Set `Enable webhooks notifications` to Yes - You can test the hook in `Webhooks notifications configuration` sub menu - In a notification (like new ticket): - add a new link to a existing template with `webhook` mode - set recipients (you will find the dropdown you defined previously) - You are done > **Important** > The webhook notifications pass through the notification queue like emails one, so make sure the automatic action for send notification in queue is active and functionnal. > **Notification Models** > The above services take into input very simple HTML. > We recommend to set new and distinct notification templates from emails one. > Keep it simple! ## Screenshots ![Mattermost messages](https://services.glpi-network.com/documentation/1533/download_file/main/docs/screenshots/mattermost.png) ![Setup webhooks](https://services.glpi-network.com/documentation/1533/download_file/main/docs/screenshots/setup_webhook.png) ![Setup notification](https://services.glpi-network.com/documentation/1533/download_file/main/docs/screenshots/setup_notification.png) ## Notification / WebHook / Target: explanation This documentation is intended to explain the different ways of sending notifications according to the targets of the webhooks and the recipients of the notifications ## Collaborative tools settings In this documentation we will use two different webhooks ### Webhook A (without user target) This first webhook does not use any targets ![](https://services.glpi-network.com/documentation/1533/download_file/main/docs/screenshots/upload_a118bb326ee529994b13500cc2e07cfa.png) ### Webhook B (with user target) This second webhook defines the user ```tech``` as the target. ![](https://services.glpi-network.com/documentation/1533/download_file/main/docs/screenshots/upload_34089c6c48e4ee2f45173f4792d15ea9.png) ## Use Case 1 The **New user in assignees** notification defines as a recipient **only**: * Technician in charge of the ticket ![](https://services.glpi-network.com/documentation/1533/download_file/main/docs/screenshots/upload_2af40b6fbd98e3fbf44b5767b7292efd.png) ### User assigned is defined as recipients and as target Assigning user ```tech``` as a technician on a ticket will have the following behaviour: :::success Even if the ```Webhook B (with user tech as target)``` is not declared in the list of recipients of the GLPI notification, it is still triggered by the plugin, because the recipient (```tech``` user) corresponds to the defined target. ::: :::danger The ```Webhook A (without user target)``` is not triggered ::: ### User assigned is defined as recipients and as target Assigning user ```tech 2``` as a technician on a ticket will have the following behaviour: :::danger ```Webhook B (with user tech as target)``` is not triggered because ``` user != target```. ::: :::danger The ```Webhook A (without user target)``` is not triggered ::: ## Use Case 2 The **New user in assignees** notification defines as a recipient: * Webhook A (without target) * Webhook B (with target) ![](https://services.glpi-network.com/documentation/1533/download_file/main/docs/screenshots/upload_613face48627d59d2bdade43dbf17812.png) ### User assigned is defined as recipients and as target Assigning the ```tech``` user as a technician on a ticket will have the following behaviour: :::success ```Webhook A (without user target)``` is triggered ::: :::success ```Webhook B (with user tech as target)``` is triggered ::: ### User assigned is defined as recipients but not as a target Assigning the ```tech 2``` user as a technician on a ticket will have the following behaviour: :::success ```Webhook A (without user target)``` is triggered ::: :::success ```Webhook B (with user tech as target)``` is triggered even if ```user != target``` ::: ## Use Case 3 The **New user in assignees** notification defines as a recipient : * Webhook A (without target) * Webhook B (with target) * Technician in charge of the ticket ![](https://services.glpi-network.com/documentation/1533/download_file/main/docs/screenshots/upload_3106d204a9ef7560e0ad874c1acc2721.png) ### User assigned is defined as recipients and as target Assigning the ```tech``` user as a technician on a ticket will have the following behaviour: :::success ```Webhook A (without user target)``` is triggered ::: :::success ```Webhook B (with user tech as target)``` is triggered because : * the user assigned to the ticket **is** the recipient of the notification * the user assigned to the ticket **is** the target of the webhook ::: ### User assigned is defined as recipients but not as a target Assigning the ```tech 2``` user as a technician on a ticket will have the following behaviour: :::success ```Webhook A (without user target)``` is triggered ::: :::danger ```Webhook B (with user tech as target)``` **is not triggered** because : * the user assigned to the ticket is the recipient of the notification * the user assigned to the ticket **is not** the target of the webhook ::: [[toc]]
